And Matrox Inspector supports Microsoft® Windows® Me, Windows NT® 4.0, Windows® 2000 and Windows® XP Matrox Meteor-II/1394 IEEE 1394-to-PCI adapter board for digital video acquisition. Simplified, High-performance Digital Video Capture Matrox Meteor-II/1394 is an IEEE 1394-to-PCI adapter board for simplified. Matrox CON3FE Network Interface Card - Triple-port PCIex1 IEEE 1394 adaptor card pre-licensed for MIL Interface package (IEEE 1394 IIDC driver). Simple Type: Network Interface Card. Download the datasheet (PDF).

Matrox ConcordFamily of Gigabit Ethernet NICs and IEEE 1394b adaptors.Digital video interface cards for industrial imagingKey featuresMatrox Concord is a family of Gigabit Ethernet network interface cards (NICs) and IEEE ®1394b adaptors that are pre-licensed for use with the Matrox Imaging Library (MIL) PCIe x1 or conventional 32-bit PCI ®low-profile card drivers for the GigE Vision and IEEE 1394 IIDC protocols. The Matrox Concord family offers a long and stable life cycle, which eliminates the burden associated with sourcing lifecycle managed and long term availabilityand qualifying consumer-grade boards.®GigE Vision or IIDC support through Matrox Imaging Library (MIL)Support for established interface standardspre-licensed for use with MIL GigE The Matrox Concord G-series are Gigabit Ethernet NICs that provide optimum support ®Vision or IIDC drivers ®for the GigE Vision camera interface standard. By way of MIL, these NICs are optimally ®configured to minimize GigE Vision protocol loading on the host through the default pre-configured for optimal GigE ®Vision performance (G-series)enabling of jumbo packets as well as optimal settings for the interrupt throttling rate and number of receive buffers. Unlike generic NICs, using the Matrox Concord fingerprint for, and storage of, supplemental MIL run-time G-series with MIL does not require manually adjusting advanced driver properties. 1license(s)Auto medium-dependent interface crossover (MDIX) further simplifies setup by programmed using Matrox Imaging automatically detecting and crossing over signals for peer-to-peer connections thereby Library (MIL) sold separatelyeliminating the need for special cables. ®supports 32/64-bit Microsoft ® ® ®2Windows XP/Vista /7 and Linux The Matrox Concord F-series are IEEE 1394b adaptors that, through MIL, enable the through MILuse of leading IEEE 1394 industrial cameras implementing the standard IIDC protocol. 3These adaptors, by way of MIL, support up to the S400 and S800 modes of IEEE 1394a and 1394b respectively, ensuring maximum camera performance and minimal transfer latency. In addition, the use of bilingual copper connectivity permits for cost-effective cabling.Matrox Concord GE/GXMIL license MAC / Link Physical 10/100/1000 Mbpsfingerprint RJ45 Layer Layer Ethernetand Controller Controllerstorage® ® 5V/3.3V, 32-bitPCIe x1 (GE)Conventional PCI (GX)(up to 250 MB/s)(up to 260 MB/s)Matrox Concord FE/FX9-pin IEEE 1394a/b Physical Layer IEEE 1394b with powerControllerMIL MIL Lic License ense 9-pin IEEE 1394a/b Physical Layer Link Layer Link LayerIEEE 1394b with power ControllerFingerprint Fingerprint Contr Controll oller erand Storage and Storage9-pin IEEE 1394a/b Physical Layer IEEE 1394b with powerController5V/3.3V, 32-bit® ®PCIe x1 (FE)Conventional PCI (FX)(up to 250 MB/s)(up to 130 MB/s)Field-proven application development software Managed lifecycleMatrox Concord is supported by the Matrox Imaging Library Matrox Concord boards are manufactured with strict change (MIL), a comprehensive collection of software tools for developing control to ensure a consistent supply through a long life cycle. industrial imaging applications. MIL features interactive software Longevity of stable supply lets OEMs achieve maximum return and programming functions for image capture, processing, on the original investment without incurring the additional costs analysis, annotation, display and archiving. These tools are associated with qualifying new boards.designed to enhance productivity, thereby reducing the time and effort required to bring your solution to market. Refer to the MIL datasheet for more information.2Specifications Specifications (Cont.)Matrox Concord GE/GX - Hardware Environmental information• operating temperature: 0°C to 55° C (32° F to 131° F)®• PCIe x1 (GE) or 32-bit, 66 MHz conventional PCI (GX) • relative humidity: up to 95% (non-condensing) universal (3.3V/5V) host bus interface®• Intel Gigabit Ethernet PHY/MAC/Link controllerCertifications• single port• handles 10/100/1000 Mbps connections• FCC part 15 class A • supports Jumbo frames/packets up to 9014 bytes• CE class A• selectable interrupt moderation rate• RoHS-compliant• resizeable receive buffers/descriptors• supports auto MDIX (signal crossover)Software Drivers• standard RJ45 connector• Matrox Imaging Library (MIL) drivers for 32/64-bit ® ® ®Power consumption and Dimensions Microsoft Windows XP/Vista /7• GE: 3.3V @ 0.44 A (1.45 W) typical• GX: 5V @ 0.4 A (2 W) typical4• PCI low-profile , sub-half-length• GE: 7.4 cm L x 6.9 cm H x 1.6 cm W (2.9” x 2.7” x 0.62”) from bottom edge of goldfinger to top edge of board and without bracket• GX: 11.9 cm L x 6.4 cm H x 1.6 cm W (4.7” x 2.5” x 0.62”) from bottom edge of goldfinger to top edge of board and without bracketMatrox Concord FE/FX - Hardware®• PCIe x1 (FE) or 32-bit, 33 MHz conventional PCI (FX) universal (3.3V/5V) host bus interface• Texas Instruments physical/link layer controller• OHCI compliant• three (3) bilingual IEEE 1394a/b ports• 9-pin connector for copper cabling• provides power (up to 12 W per port)Power consumption and Dimensions• FE: 3.3V @ 0.33 A (1.1 W) typical• FX: 5V @ 0.2 A (1 W) typical4• PCI low-profile , half-length• FE: 8.6 cm L x 6.9 cm H x 1.6 cm W (3.4” x 2.7” x 0.62”) from bottom edge of goldfinger to top edge of board and without bracket• FX: 11.9 cm L x 6.4 cm H x 1.6 cm W (4.7” x 2.5” x 0.62”) from bottom edge of goldfinger to top edge of board and without bracket 3Ordering Information HardwarePart number & Description®CON 1G E* Single-port PCIe x1 Gigabit Ethernet network interface card (NIC) pre-licensed for MIL Interface ®package (GigE Vision driver). Acts as a finger-print for, and handles storage of, supplemental MIL license(s).CON 1G X* Single-port 32-bit conventional PCI Gigabit Ethernet network interface card (NIC) pre-®licensed for MIL Interface package (GigE Vision driver). Acts as a fingerprint for, and handles storage of, supplemental MIL license(s).®CON 3F E* Triple-port PCIe x1 IEEE 1394 adaptor card pre-licensed for MIL Interface package (IEEE 1394 IIDC driver). Acts as a fingerprint for, and handles storage of, supplemental MIL license(s).CON 3F X* Triple-port 32-bit conventional PCI IEEE 1394 adaptor card pre-licensed for MIL Interface package (IEEE 1394 driver). Acts as a fingerprint for, and handles storage of, supplemental MIL license(s).SoftwareRefer to MIL datasheet.Notes:1. Feature not supported under Linux.2. Only with Matrox Concord G-series. 3. S800 mode is supported under 32-bit Windows® XP, with a partial roll back to SP1 if using SP2 and 64-bit Windows® XP. S800 mode is not supported under 32/64-bit Windows® Vista®. 4. Contact local representative or Matrox Imaging Sales for availability of optional low-profile I/O bracket.Corporate headquarters:Matrox Electronic Systems Ltd.1055 St. Regis Blvd.Dorval, Quebec H9P 2T4CanadaTel: +1 (514) 685-2630 Fax: +1 (514) 822-6273For more information, please call: 1-800-804-6243 (toll free in North America) or (514) 822-6020 or e-mail: [email protected] or http://www.matrox.com/imagingAll trademarks by their respective owners are hereby acknowledged. Matrox Electronic Systems, Ltd. reserves the right to make changes in specifications at any time and without notice. The information furnished by Matrox Electronic Systems, Ltd. is believed to be accurate and reliable. However, no responsibility license is granted under any patents or patent rights of Matrox Electronic Systems, Ltd. Windows and Microsoft are trademarks of Microsoft Corporation. © Matrox Electronic Systems, 2008-2011. Printed in Canada, 2012-03-20 $IE-5412-B

New FireWire Bus Driver Package

Matrox meteor ii 1394 driver

AVT 1394 Bus Driver Package

Matrox 1394 Driver Windows 10

Allied Vision Technologies recently released the AVT 1394 Bus Driver package for Windows. The AVT 1394 Bus Driver eliminates the existing speed limitations of the original Windows driver with 1394b.

The AVT 1394 Bus Driver Package contains an alternative 1394 bus driver that is compliant to the native OHCI 1394 bus driver provided with Microsoft Windows. This means unlike other proprietary 1394 bus drivers that are incompatible to the one provided with Microsoft Windows, existing custom 1394 device drivers (e.g. for hard disks) will continue to work with the AVT Bus Driver.

Matrox Meteor Ii 1394 Driver

Additionally, in combination with AVT cameras the AVT 1394 bus driver can be used with 1394 camera drivers provided by 3rd-party solutions like Cognex’s Vision Pro, or MATROX’s MIL, as well as the CMU ( Carnegie Mellon University) 1394 camera driver.
AVT 1394b cameras will therefore run at full S800 data rate (800Mbps) under Windows Vista and XP (SP2/SP3) while also supporting other non camera Firewire devices. This is only possible because the AVT 1394 bus driver eliminates the existing speed limitations of the original Windows driver.
When installed the driver replaces the existing 1394 card driver. The installation and de-installation of the driver can be performed via an easy to use driver install tool that is part of the package.
Supported Operating Systems
- Windows Vista SP1
- Windows XP SP2/SP3
- Windows 2000 SP4


Key features of the AVT 1394 bus driver:
- Optimized for high-throughput, low CPU load and fault-tolerant operation
- Can be used with 32-bit Windows operating systems Vista, XP, and 2000 only
- Supports all AVT 1394 cameras
- Supports all current IEEE 1394 standards (1394a and 1394b)
- Supports OHCI-compliant host controllers
- Implementation conforms to the PCI driver model defined by the Windows Driver Model
- No licensing fee when used with AVT 1394 cameras
Adept Electronic Solutions are 'The machine vision and imaging specialists' providing expert advice and timely support. To find out more about the AVT 1394 bus driver package or any other AVT product please email us at: [email protected], call us at Perth (08) 92425411 / Sydney (02) 99792599 / Melbourne (03) 95555621 or use our online contact us form.
